Description
Product Features:
- Adjustable Functions:
- Backrest (0°–70°±5°), Legrest (0°–40°±5°), and Height (450–750±10 mm) with auto-contour feature for optimal patient comfort.
- Three High-Quality Motors:
- Quiet, durable motors, operated via a remote control for smooth and reliable adjustments.
- Safety Features:
- Fully length side rails with a disc-shaped damping slow-down device, ensuring safe, noiseless, and smooth operation.
- Safety gap design to comply with IEC 60601-2-52 standard, minimising risk of patient falls.
- Emergency and Convenience Features:
- Removable headboard and footboard for emergency use, transforming into a CPR board for quick medical intervention.
- Corner bumpers provide shock absorption and protect patients from injuries.
- Additional Comfort and Functionality:
- Radiolucent backrest board and optional X-ray cassette to facilitate diagnostic imaging.
- Blue liquid angle indicators clearly display bed positioning on both backrest and legrest side rails.
- Bedside card for patient name display, along with four infusion holes and two drainage hooks for added convenience.
- Optional Features:
- Orthopedic traction frame holes on all four corners for use in orthopedic clinical applications.
- Mobility:
- Four 125mm diameter castors with central brake system ensure easy movement and secure positioning.
Product Materials:
- Frame: Cold-rolled steel with electrostatic powder coating for durability and long-term use.
- Side Rails & Bed Platform: HDPE plastic, easy to clean and detachable.
- Headboard/Footboard: Detachable HDPE for convenience and hygiene.
- Corner Bumpers: Durable, elastic material for enhanced patient protection.
Product Parameters:
- Bed Platform: 1980 x 900 mm
- Backrest: 0°–70°±5°
- Legrest: 0°–40°±5°
- Height Adjustment: 450–750±10 mm
- Brakes: Central Brake
- Motor: 3 Motors
- Control Panel: Remote Control
- Material Finish: Wood Grain Lake Blue
